Product Details:
|
Name: | Vibrating Drying Machine | Type: | Dewatering Machine, Cooling Machine |
---|---|---|---|
Voltage: | 220v/380v, 380V, 220V,customized | Dimension(L*W*H): | 4000*1200*1480MM |
Power: | 10.1KW | Weight: | 600KG |
Material: | SUS304 | Belt Width: | 800mm |
High Light: | Dewatering Vibrating Screen Sieve,Vibrating Screen Sieve 300kg/H,700mm Belt Vibrating Screen Sieve |
industrial easy operation continuous conveyor belt type air dry machine
Model | Dimension | Motor power | Belt width | Capacity |
ZYZD-300 |
2000*800*1100mm |
1.1kw | 700mm | 300 kg/h |
ZYZD-400 | 3000*800*1100mm | 1.75kw | 700mm | 500 kg/h |
ZYZD-500 | 4000*800*1100mm | 2.5kw | 700mm | 700 kg/h |
ZYZD-600 | 5000*800*1100mm | 3.75kw | 700mm | 900 kg/h |
the material enters from the feed end and vibrates forward through the vibration eccentric device, which can better realize that the material will remove most of the water droplets as soon as possible, and then enter the air trunk line or directly pack it, which greatly shortens the drying time of the material. .
1. Fully enclosed structure, no dust spillage;
2. Screen replacement is simple and fast, only 3 to 5 minutes, screen material has a variety of options.
3. It can be designed according to the user's requirements.
4. low energy consumption, high output, easy maintenance
