Product Details:
|
| Name: | Vacuum Freeze Drying Lyophilizer | Function: | Vegetable Fruit Dehydrator |
|---|---|---|---|
| Key Selling Points: | Easy To Operate | Weight: | 1000kg |
| Dry Area: | 1.08 Square Meter | Core Components: | Pump, Motor, Gearbox, PLC, Engine |
| Warranty Of Core Components: | 1 Year | Temperature Range: | -45℃-70°C |
| High Light: | 380V Food Vegetable Drying Equipment,Strawberry Food Vegetable Drying Equipment,PLC Food Vegetable Drying Equipment |
||
| Please contact us about how to place an order: | |
| Contact Person: | Mrs. Lisa |
| Job Title: | Manager |
| Business Phone: | 086 15249674563 |
| WhatsApp: | 086 15249674563 |
| WeChat: | 086 15249674563 |
| Skype: | 086 15249674563 |
| Email: | Sale@frenchfriesline.com/Lisa@frenchfriesline.com |
Description by Manufacturer
Freeze dryer is designed for freeze drying food material. It requires a large production capacity, lower equipment cost and lower cost on energy consumption.
Feature of freezing drying machine
|
Technical Features
|
|
|
1
|
The vacuum pump has been stable operation ensure
|
|
2
|
Vacuum pump check valve of high performance and vacuum pump can avoid backing due to the difference of atmospheric when pump stops
|
|
3
|
Multi-stage vacuum setting function, you can achieve a degree of vacuum freeze-drying cycle to control of multiple variables
|
|
4
|
Vacuum pump connected to the chamber isolated by electric vacuum solenoid valve he pump features an automatic isolating valve to
hold the chamber pressure in the event of power failure or vacuum valve not reach as set point. |
Specification of freezing drying machine
|
Power
|
380V/50Hz/3P(Can be customized)
|
|
Type
|
Conductive Type
|
|
Capacity(kg/batch)
|
100kg
|
|
Condenser Temperature(℃)
|
-45℃
|
|
Shelf Temperature(℃)
|
-30 to 60℃
|
|
Pre-freezing
|
in original place
|
|
Usable Shelf Area(㎡)
|
10㎡
|
|
Number of Shelves
|
8+1
|
|
Shelf Dimension(m)
|
1.6*0.8(Can be customized)
|
|
Number of Product Trays
|
16pcs
|
|
Refrigerant
|
R404a(Can be customized)
|
|
Weight(kg)
|
2500kg
|
Food freeze drying equipment vegetable fruit slices vacuum freeze dryer machine
 |
Working principle of freeze dry:
In a sealed vacuum surrounding, by heating the complete frozen food material, the moisture in the frozen material will be evaporated to a continuous frozen vapor condenser. After 20-30 hours, the food material is dried, the water is moved to vapor condenser of the freeze dryer.
|
Application of our freeze dryer:
Vacuum freeze-drying technology is applied to process food material to make freeze dried food. The freeze dryer is used in all conceivable kinds of agricultural products with top drying quality. Fruits: durian, strawberry, mango, apricot, kiwifruit, pineapple, lemon, raspberry, avocado, banana etc. Vegetables: broccoli, parsley, mushroom, bean, scallion, asparagus, onion, celery, carrot, tomato, pepper etc. Other food: beef, coffee, colostrums, herbal, flower, tea, honey, sea food and all kinds of pets food.
Freeze-drying equipment style:
1, Contact freeze dryer: better for liquid material, mainly for small or mudium production.
The plates and trays are constructed by stainless steel.
2, Radiant freeze dryer: better for solid material, mainly for mudium or large scale production.The plates and trays are constructed by aluminum, with IQF. The refrigeration is in IQF and heating on the plates, and the material is loaded by trolley on the track system.
Application of our freeze dryer:
Vacuum freeze-drying technology is applied to process food material to make freeze dried food.The freeze dryer is used in all conceivable kinds of agricultural products with top drying quality.
Fruits: durian, strawberry, mango, apricot, kiwifruit, pineapple, lemon, raspberry, avocado, banana etc.
Vegetables: broccoli, parsley, mushroom, bean, scallion, asparagus, onion, celery, carrot, tomato, pepper etc.
Other food: beef, coffee, colostrums, herbal, flower, tea, honey, sea food and all kinds of pets food.
Why to choose freeze dryer?
Do you hope to have an equipment to dry fresh food material without nutrition lost, and meanwhile preserves its original taste, flavor and color? Only freeze dryer can meet this requirement. Do you want to get the most healthy dried food with the lowest cost far away from those outrageously expensive pharmaceutical freeze-dryers? Our freeze dryer can make it.
